Electric Aluminum Spiral Rapid Door

Qingdao Norton Door Technology Co., Ltd. proudly launches its electric Electric Aluminum Spiral Rapid Door product, an industrial door solution that integrates high efficiency, high safety, and excellent design. This product adopts advanced aluminum alloy materials and turbine drive technology, and is tailored for industrial and commercial environments that pursue high efficiency, safety, and aesthetics.Qingdao Norton Door Technology Co., Ltd. is proud to introduce its electric Electric Aluminum Spiral Rapid Door, an industrial door solution that integrates high efficiency, high safety, and excellent design. This product adopts advanced aluminum alloy materials and turbine drive technology, tailored for industrial and commercial environments that emphasize efficiency, safety, and aesthetics.

The electric Electric Aluminum Spiral Rapid Door boasts excellent door panel performance, fast operation speed, and utilizes advanced control systems, while occupying minimal installation space.

Product Parameter

Product Feature And Application

The electric Electric Aluminum Spiral Rapid Door employs a spiral circular non-contact track system, ensuring that the panels remain unconnected to each other during the rolling process. This design prevents wear and deformation of the panel material, significantly reducing friction and enabling the door to operate swiftly and silently.

The door operates smoothly, swiftly, and with stability, making it ideally suited for high-frequency usage scenarios. Its seamless and efficient performance ensures uninterrupted flow in industrial and commercial environments where time and efficiency are paramount.

Product Details

Material and structural design

Aluminum alloy material: the door body is made of advanced aluminum alloy material, which is not only light and strong, but also has good corrosion resistance and oxidation resistance, and is suitable for various industrial and commercial environments.

Spiral circular non-contact track: the unique spiral circular non-contact track design is adopted. When the curtain is rolled up, the panels are not connected with each other, which avoids material wear and deformation, reduces friction and improves the running speed and mute performance of the door.

(1) Door Panel thickness is not less than 40mm.
(2)The surface is anodized and organic colored.
(3)The interior is filled with polyurethane (excluding CFC) foam.
(4)Adopt international advanced bridge insulation treatment.
(5)The hinge load-bearing design makes the curtain joints unstressed, the door panels are not in contact, and the flatness can be maintained after long-term use.

Three lift styles

According to the door opening headroom, there are 3 lift styles optional.
Circular Spiral guide rail headroom: Min 0.85m for 3m height door. Min 1m for 5m height door
Oval Spiral guide rail headroom: Min 0.7m.

Blowing Machine Bottle Making

Machine Bottle Moulding Machine.

Multiple opening methods

Infrared safety light curtains are installed on both sides of the door body. When an object or a person passes through the light curtain, the door body will immediately stop closing or reverse opening to prevent safety accidents such as pinching.

Bottom airbag: an airbag is installed at the bottom of the door body. When the door body encounters an obstacle in the closing process, the airbag will quickly inflate and jack up the door body to avoid damage or injury to the obstacle.

Between the door panels, all sides are equipped with sealing strips, the door panels are filled with polyurethane foam material,heat insulation and noise prevention

Motor

Electric control box: The electric control box has a LED touch screen with on, off, and stop buttons, and an emergency stop
switch. In case of emergency, the control loop power can be quickly cut off to protect people and machines.

Function of LED touch screen: displaying the fault code, easily modify the operating parameters and set the system password.

Limit: Absolute encoder
Output speed: 100R/Min Function: adjustable speed, rebound resistance, Chinese and English menu, fast clutch, slow start and slow stop

Output aperture: Dia.25.4mm Operating temperature range: -20 to 45°C A variety of interfaces: infrared, airbags, small door contact switches, warning lights, geomagnetic and so on。

Electric Aluminum Spiral Rapid Door Production:
Qingdao Norton Door Technology Co., Ltd. focuses on the production of electric aluminum spiral rapid doors with the aim of satisfying customer needs. We provide a one-stop service from design, production to installation and maintenance, ensuring that customers have no worries during use. The company boasts excellent production equipment and a skilled technical team, enabling us to efficiently and accurately complete the production tasks of electric aluminum spiral rapid doors.

Electric Aluminum Spiral Rapid Door Packaging:
We promise that our products are delivered in a ready-to-install state, requiring no additional operations, making installation easy and hassle-free for your convenience.

Packing Details :

 For full container order, carton box package.  For partial container order, packed by wooden box.

Delivery
